Project Overview
ISKAR successfully completed the design and manufacturing of a ship loader with a capacity of 1,100 tph for Wondernet Express Carbamide Terminal at Batumi Port, Georgia. The ship loader was commissioned in 2020.
ISKAR Mühendislik Ltd. is a solution provider and turnkey contractor specializing in material handling machinery, with particular expertise in port and dock cranes. ISKAR delivers innovative engineering solutions and state-of-the-art, custom-engineered cranes designed to meet each customer's specific requirements.
Batumi Port Ship Loader
Technical Specifications
| Loading Material | Mineral fertilizers |
| Material Bulk Weight | 720 – 1200 kg/m³ |
| Volumetric Loading Capacity | 1500 m³/h |
| Loading Capacity | 1100 t/h |
| Vessel Type | Bulk Carrier |
| Vessel Size | 5000 – 50000 DWT |
| Loading Chute Reach (from middle of rail span) | 30,0 m |
| Gantry Gauge (span between middle of rails) | 10500 mm |
| Vertical Clearance under Gantry, approx. | 9.0 x 6.0 m |
| Type of Jetty Rail | P 65 |
| Number of Wheels (sea side) | 8 Nos |
| Number of Wheels (land side) | 6 Nos |
| Travel Distance to Each Side of Electrical Feeding Point, approx. | 100 m |
| Total Travel Distance | 200 m |
| Conveyor Belt | 2.4 m/s |
| Slewing Structure | 0.5 rpm |
| Luffing Cylinder | 22 (28) mm/s |
| Travelling | 25.0 m/min |
| Electric System | 400V 3ph 50Hz |
